4 Inch TFT LCD Display With Capacitive Touchscreen

Product Categories

Hotdisplay Technology Co.Ltd

Contact Now

4 Inch TFT LCD Display With Capacitive Touchscreen

Name: 4 Inch TFT LCD Display With Capacitive Touchscreen
Brand: HOTHMI
Price: 1 USD

China 4 Inch TFT LCD Display With Capacitive Touchscreen factory

Brand Name : HOTHMI

Model Number : TFT-H040A1PVIST3C40

Place of Origin : dongguan,China

MOQ : 2

Payment Terms : L/C, D/A, T/T, D/P, Western Union, MoneyGram

Supply Ability : 99999

Delivery Time : 25 days

Product Type : Square TFT

Display content : 480x480 dots

Dimensions (mm) : 83.90(H) * 83.90(V) * 3.21(D)

Supply voltage : 3.3V

Driver chip model : ST7701S,FT6336U

Special instructions : with capacitive touch function

Contact Now

4 Inch 480x480 TFT LCD Module SPI FT6336U Capacitive Touch Screen/TFT-H040A1PVIST3C40

Product parameters
Field of view window size (mm) - 4 inch
Display Size(mm) - 4 inch
Effective Dimensions mm - 71.86(H) x 70.18(V)
Product application - 86 boxes, smart panel
Angle - Full Angle
Backlight brightness - 350cd/m2
Connection method PIN number - 40PIN
Interface - 18 bit RGB+SPI
Working temperature - -20~70℃

General Feature

ITEM	PARAMETER DESCRIPTION	UNIT
TFT series	TFT-H040A1PVIST3C40
Diagonal size	4.0”	Inch
Resolution	480x480	Dot
Dimensions	83.9X83.9X3.21	mm
Active area (AA)	71.86X70.18	mm
LCD type	TFT LCD Display	mm
Display viewing angle	Full View(U80/D80/R80/L80)
Aspect ratio	1:1
Backlight type	LED white
TFT driver IC	ST7701S
Brightness	350	cd/m2
Operating temperature	-20~70℃	℃
Storage temperature	-30~80℃	℃

DESCRIPTION
HOTLCD H040A1 is 480x480 dots TFT LCD module display with 4.0" TFT capacitive touch screen and it is easily controlled by SPI WITH RGB. This 4.0" TFT LCD with touch screen can be used in embedded systems, industrial device, 86 boxes, smart home panels equipment which require display in high quality and colorful image. It supports RGB WITH SPI interface.

Search keyword: tft 4, tft 4", 4 tft lcd, 4" tft 4, 4 inch tft lcd, tft lcd 4, 4 tft display, 4" tft display, 4 inch tft display, tft display 4, tft display 4", 4 lcd

4 Inch TFT LCD Display With Capacitive Touchscreen

SPEC-H040A1-V3-0.pdf
